1100 mm (43 in)

1100 mm (43 in) Nordic Grading Bucket

Ideal usage for grading applications, but suitable for general excavation, loading, and backfilling in all kinds of different soil types up to heavy duty applications.

Application

Designed to create maximum performance in combination with a tiltrotator equipped with an S-Type or pin grabber coupler.

Wear Protected Side Plates

Specially designed side wear plates provide for optimal wear resistance in heavy duty applications.

Torque Tube

For low build bracket solution, close to zero offset and high bending resistance even during high stress work.

Conical / Tapered Side Plates

Special shape allows for easy bucket filling and emptying as well as inner trench rotating capabilities while using in conjunction with a tiltrotator.

Short Tip Radius and Long Floor

With high breakout forces combined with tiltrotator usage, the bucket still produces acceptable bucket volumes.

Additional information

Offering Type

Width

1100 mm ( 43.3 in )

Capacity

150 l ( 5.3 ft³ )

Weight

115 kg ( 253.5 lb )

Base Edge Thickness

15 mm ( 0.6 in )

Tip Radius

536 mm ( 21.1 in )

Interface Type

S-40
