508 mm (20 in)
508 mm (20 in) Heavy Duty Bucket
High strength buckets designed for maximum performance and value over a broad range of applications.
Application
Cat® Heavy Duty Buckets are well suited for semi-rocky soil or where hard bank material must be broken out and removed. Ideal for utility trenching, digging footings, back-filling and general excavating in construction, landscaping and utility applications.
Bucket Design
Formed back wrapper design enhances bucket loading ability and production.
Superior Bucket Fill
Optimum wrapper angle and no sharp corners promote superior bucket fill and reduce material packing.
Bucket Shape
Enhanced bucket shape allows material to flow more easily. Tapered bucket sidewalls allow for easy dumping of sticky material.
Videos
Documents & Brochures
Additional information
| Offering Type | |
|---|---|
| Width | 508 mm ( 20 in ) |
| Capacity | 93.4 l ( 3.3 ft³ ) |
| Weight | 87 kg ( 191.8 lb ) |
| Base Edge Thickness | 20 mm ( 0.8 in ) |
| Tip Radius | 710 mm ( 28 in ) |
| Interface Type | Pin On |
-
