824K

824K Wheel Dozer

Cat Wheel Dozers are designed with durability built in, ensuring maximum availability through multiple life cycles. With optimized performance and simplified serviceability, our machines allow you to support your job site efficiently and safely while lowering owning and operating costs. The 824K continues our legacy of reliability, performance, safety, operator comfort, serviceability, and efficiency.

Efficiency and Productivity

Long Term Value and Durability

Built to Perform

Work in Comfort

Integrated Cat® Technologies

Save on Service and Maintenance

Top-Tier Service and Support

Safety First

Reduce Environmental Impact

Purpose-Built Cat Attachments

Save on Fuel Costs

Standard Equipment

NOTE
  • Standard and optional equipment may vary. Consult your Cat dealer for details.
POWER TRAIN
  • Air to air aftercooler
  • Auto shift
  • Brakes, full hydraulic, enclosed, wet multiple disc service brakes
  • Cat clean emission module (Tier 4 Final/Stage IV equivalent)
  • Electro-hydraulic parking brake
  • Electronic Clutch Pressure Control (ECPC)
  • Engine, Cat C15: – U.S. EPA Tier 4 Final/EU Stage IV equivalent – U.S. EPA Tier 3/EU Stage IIIA equivalent
  • Fuel priming pump (electric)
  • Fuel to air cooler
  • Ground level engine shutoff
  • Hydraulically driven demand fan
  • Integrated braking system
  • Muffler (under hood) (Tier 3/Stage IIIA equivalent)
  • Radiator, Aluminum Modular (AMR)
  • Separated cooling system
  • Single Clutch Speed Shifting (SCSS)
  • Starting aid (ether) automatic
  • Throttle lock
  • Torque converter with Lock Up Clutch (LUC)
  • Transmission, planetary, with 4F/4R speed range control
ELECTRICAL
  • Alarm, back-up
  • Alternator, 150 amp
  • Batteries, maintenance-free (4 – 1,000 CCA)
  • Electrical system, 24V
  • Ground level lockable master disconnect switch
  • Light, warning switched (LED strobe)
  • Lighting, access stairway
  • Lighting system, halogen (front and rear)
  • Lights, directional (rear)
  • Starter, electric (heavy duty)
  • Starting receptacle for emergency start
OPERATOR ENVIRONMENT
  • 12V power port for mobile phone or laptop connection
  • Air conditioner
  • Cab, sound-suppressed pressurized
  • Cab door, sliding window (LH)
  • Cab Integrated Object Detection System (CIODS) ready
  • Coat and hard hat hooks
  • Electro-hydraulic tilt and lift controls
  • Finger tip shifting controls
  • Flip-up armrest
  • Heater and defroster
  • Horn, electric
  • Implement hydraulic lockout
  • Instrumentation, gauges: – DEF fluid level (Tier 4 Final/Stage IV) – Engine coolant temperature – Fuel level – Hydraulic oil temperature – Speedometer/tachometer – Torque converter temperature
  • Instrumentation, warning indicators: – Action alert system, three categories – Brake oil pressure – Electrical system, low voltage – Engine failure malfunction alert and action lamp – Parking brake status
  • Laminated glass
  • Light, (dome) cab
  • Lunch box and beverage holders
  • Internal four-post rollover protective structure (ROPS/FOPS)
  • Mirror, internal (panoramic)
  • Mirrors, heated ready
  • Mirrors, rearview (externally mounted)
  • Radio ready for entertainment: – Antenna – Speakers – Converter (12V, 10-15 amp)
  • Seat, Cat Comfort (cloth) air suspension
  • Seat belt with minder, retractable, 76 mm (3 in) wide
  • STIC control system with lockout
  • Sun visor, front
  • Tinted glass
  • Transmission gear (indicator)
  • Vital Information Management System (VIMS): – Graphical information display – External data port – Customizable operator profiles
  • Wet-arm wipers/washers (front and rear): – Intermittent wipers (front and rear)
GUARDS
  • Guard, driveshaft
  • Guards, crankcase and power train
FLUIDS
  • Antifreeze, premixed 50% concentration extended life (–34° C/–29° F)
OTHER STANDARD EQUIPMENT
  • Doors, service access (locking)
  • Ecology drains for engine, radiator, transmission, hydraulic tank
  • Emergency platform egress
  • Engine, crankcase, 500 hour interval with CJ-4 oil
  • Engine idle management features: – Auto idle kickdown – Delayed engine shutdown – Engine idle shutdown
  • Fire suppression ready
  • Fold down exhaust stack for shipping
  • Fuel tank, 782 L (207 gal)
  • Hitch, drawbar with pin
  • Hoses, Cat XT
  • Hydraulic, engine, and transmission oil coolers
  • Oil change system, high speed
  • Oil sampling valves
  • Product Link
  • Secondary steering
  • Stairway, left and right rear access
  • Steering, load sensing
  • Toe kicks
  • Total hydraulic filtration system
  • Vandalism protection caplocks
  • Venturi stack
