C32B
C32B
All new from the block up and built on the proven C32 platform, the C32B marine engine delivers more power, more speed, more time on the water and more peace of mind. All that comes in a quieter package with only a 2% increase in weight compared to the previous model — making the C32B the right choice for new builds and repowers. Rated at 2025 mhp (2000 bhp) / 1491 bkW @ 2300 rpm, the C32B meets U.S. EPA Marine Tier 3 and IMO II emissions standards. With an E Tier rating, it can run at the full 2000hp up to 8% of the time.
Key Features & Benefits
- Electronically Governed and Controlled (ADEM VI ECM)
- Noise Reduction at low engine speeds (MEUI-C Fuel System)
- Improved Acceleration Capability
- Gear-driven Jacket Water Pump and Sea Water Pump for Enhanced Reliability
- MCS Certifications Available
- Titanium Plate Heat Exchanger
- LH and RH Service side options available
Documents & Brochures
Standard Equipment
Standard Equipment
- ADEM VI Electronic Control Module
- Air Cleaner / Fumes Disposal
- Electronic Diagnostics and Fault Logging
- Engine and Transmission Monitoring
- Sea Water Aftercooler
- Titanium Plate Heat Exchanger with Expansion Tank
- Gear-driven JW and SW pumps
- Water-cooled Exhaust Manifolds and Turbochargers
- MEUI-C Fuel System
- Fuel Priming and Transfer Pump
- 250-hr Oil Pan (Shallow Sump)
- RH or LH Service Side Options
Additional information
| المعدلات - نطاق القدرة | 2000 قدرة حصانية للفرامل (1491 كيلووات للفرامل) |
|---|---|
| المحرك - نطاق السرعة | 2300 دورة في الدقيقة |
| المحرك - الانبعاثات | وكالة حماية البيئة (EPA) من المستوى 3، المنظمة البحرية الدولية (IMO) من المستوى III |
| المحرك - السحب | TTA |
| المحرك - التجويف | 145.0 مم ( 5.71 بوصة ) |
| المحرك - الشوط | 162.0 مم ( 6.38 بوصة ) |
| المحرك - الإزاحة | 32.1 l ( 1959.0 بوصة³ ) |
| المحرك - الدوران من طرف الحدافة | عكس اتجاه حركة عقارب الساعة |
| المحرك - التكوين | ديزل على شكل حرف V ذو اثنتي عشرة أسطوانة، ذو دورة رباعية الأشواط |
| الأبعاد والأوزان - العرض | 1482.0 مم ( 58.3 بوصة ) |
| الأبعاد والأوزان - الوزن الجاف | 3145.0 كجم ( 6780.0 رطل ) |
| الأبعاد والأوزان - الطول | 2106.0 مم ( 82.9 بوصة ) |
| الأبعاد والأوزان - الارتفاع | 1445.0 مم ( 56.9 بوصة ) |
| Offering Type |
