C2.2 | DE22E3

C2.2 | DE22E3 50Hz EU IIIA EMISSIONS COMPLIANT

Producing reliable power 22.0 kVA at 50 Hz, our C2.2 diesel generator set designed to ISO 8528-5 transient response requirements. DE22E3 generator set is EU Stage IIIA emissions compliant.

Category:
Add to Quote

Cat Generator Set Package

  • Cat generator set packages have been fully prototype tested
  • Accepts 100% block load in one step and meets NFPA 110 loading requirements
  • Conform to ISO 8528-5 steady state and transient response requirements

Cat Diesel Engine

  • Reliable, rugged, durable design
  • Field-proven in thousands of applications worldwide
  • Four-stroke-cycle diesel engine combines consistent performance and excellent fuel economy with minimum weight

SR500 Alternator

  • Superior motor starting capability minimizes need for oversizing alternator
  • Designed to match performance and output characteristics of Cat diesel engines
  • Robust Class H insulation

GCCP Control Panel

  • User-friendly interface and navigation
  • Scalable system to meet a wide range of installation requirement
  • Expansion modules and site-specific programming for specific customer requirements

Cooling System

  • Designed to operate in standard ambient temperatures up to 50°C (122°F)
  • Contact your Cat Dealer for specific ambient and altitude capabilities

Certifications

  • EU Declaration of Conformity
  • EU Declaration of Incorporation
  • Eurasian Conformity (EAC)

One Safe Source

  • Components used in the generator set are selected based on seamless design integration to provide the optimum performance
  • The generator set is fully assembled at a Caterpillar facility following our quality guidelines
  • Each generator set package is tested before leaving the Caterpillar facility
  • Cat product support, including dealer service, parts and warranty covers the entire Cat power system

World Wide Product Support

  • Cat dealers have over 1,800 dealer branch stores operating in 200 countries
  • Your local Cat dealer provides extensive post-sale support, including maintenance and repair agreements

Documents & Brochures

Standard Equipment

Engine
  • Electrical system, 12 VDC
Exhaust System
  • Dry exhaust manifolds
Fuel System
  • Actuator with electronic governor

Additional information

Offering Type

Generator Set Specifications - Minimum Rating

22 kVA
Generator Set Specifications - Maximum Rating

22 kVA
Generator Set Specifications - Emissions/Fuel Strategy

R96/EUIIIa Equivalent
Generator Set Specifications - Voltage

200 to 400 Volts
Generator Set Specifications - Frequency

50 Hz
Generator Set Specifications - Duty Cycle

Standby, Prime
