Cat C32 Auxiliary / Diesel Electric Propulsion Engine (IMO III)

Cat C32 Auxiliary / Diesel Electric Propulsion Engine (IMO III)

Category:

Emissions

Utilizes SCR Technology to enable IMO III emission regulations compliance while lowering operational costs

Control Strategy

Utilizes closed loop air assisted DEF dosing control strategy that delivers: Highest efficiency mixing and control to lower operational costs; Extends emissions useful life; Ensures compliance; Flexible to urea quality

Fuel System

Enhanced control of fuel injection optimized through crank timing and the A5 ECM technology

Power Reserve

Industry leading power reserve

Certifications

Wide range of available Marine Society certifications

Warranty

Industry-leading warranty coverage for factory packaged components

Service

Global dealer network for service in any location

Standard Equipment

AIR INLET SYSTEM
  • Separate circuit aftercooled (SCAC)
  • Closed crankcase fumes disposal
CONTROL SYSTEM
  • 24V control system
COOLING SYSTEM
  • Heat exchanger or Keel Cooling
  • Watercooled exhaust manifold and turbocharger
  • Hard seawater lines – no flexible hoses
  • Flanges for cooling connections, ANSI or DIN
FUEL SYSTEM
  • Duplex fuel filters with hybrid fuel lines
  • Shipped loose primary fuel filter with water separator
  • Fuel transfer and priming pump
LUBE SYSTEM
  • Oil fill, simplex filter and dipstick
  • Deep or shallow sump oil pan
MOUNTING SYSTEM
  • Adjustable front support mounting system
GENERAL
  • Right or left hand service sides
  • Customer wiring and service tool connector

Additional information

Offering Type

Power Rating - Minimum Rating

781 bkW ( 1047 BHP )

Power Rating - Maximum Rating

994 bkW ( 1332 BHP )

Engine Specifications - Aspiration

Turbocharged-aftercooled

Engine Specifications - Displacement

32.1 l ( 1959 in³ )

Engine Specifications - Stroke

162 mm ( 6.38 in )

Engine Specifications - Rotation

Counterclockwise from flywheel end

Engine Specifications - Bore

145 mm ( 5.71 in )

Engine Specifications - Configuration

Vee 12, 4-stroke-cycle diesel

Dimensions & Weights - Maximum Engine Dry Weight

3248 kg ( 7160 lb )

Dimensions & Weights - Minimum Height

1507 mm ( 59.3 in )

Dimensions & Weights - Minimum Engine Dry Weight

3152 kg ( 6950 lb )

Dimensions & Weights - Minimum Width

1451 mm ( 57.1 in )

Dimensions & Weights - Maximum Length

2280 mm ( 89.8 in )

Dimensions & Weights - Minimum Length

2130 mm ( 83.9 in )

Dimensions & Weights - Maximum Width

1455 mm ( 57.3 in )

Dimensions & Weights - Maximum Height

1613 mm ( 63.5 in )

Engine Specifications - Emissions

IMO III emissions certified (SCR required)

Clean Emissions Module (CEM) - Dimensions - 6 Brick Z-Flow - Weight

565 kg ( 1246 lb )

Clean Emissions Module (CEM) - Dimensions - 6 Brick U-Flow - Width

1445 mm ( 56.9 in )

Clean Emissions Module (CEM) - Dimensions - 6 Brick U-Flow - Length

2159 mm ( 85.0 in )

Clean Emissions Module (CEM) - Dimensions - 6 Brick U-Flow - Height

597 mm ( 23.5 in )

Engine Specifications - Cooling

Heat exchanger or keel cooled

Engine Specifications - Flywheel Housing

SAE No. 0 with SAE No. 18 flywheel (136 teeth)

Engine Specifications - Rated Engine Speed

1500 rpm

Clean Emissions Module (CEM) - Dimensions - Dosing Cabinet - Width

477 mm ( 18.8 in )

Engine Specifications - Governor

Electronic (A5 ECM)

Clean Emissions Module (CEM) - Dimensions - 6 Brick Z-Flow - Height

597 mm ( 23.5 in )

Clean Emissions Module (CEM) - Dimensions - Dosing Cabinet - Weight

95 kg ( 209 lb )

Clean Emissions Module (CEM) - Dimensions - 6 Brick Z-Flow - Length

3751 mm ( 147.7 in )

Clean Emissions Module (CEM) - Dimensions - 6 Brick U-Flow - Weight

560 kg ( 1235 lb )

Clean Emissions Module (CEM) - Dimensions - Dosing Cabinet - Length

949 mm ( 37.4 in )

Engine Specifications - Oil Change Interval

750 hrs – deep pan

Clean Emissions Module (CEM) - Dimensions - Dosing Cabinet - Height

579 mm ( 22.8 in )

Clean Emissions Module (CEM) - Dimensions - 6 Brick Z-Flow - Width

1106 mm ( 43.5 in )

Engine Specifications - Refill Capacity

Lube Oil System w/ oil filter change: 146 L (38.5 gal) – deep pan
