320 GC – Tier 3

LATEST FEATURES


• Cab Monitor Improvements


1. Continuously improved user interface allows for intuitive navigation, minimizing performance interruption with the easy-to-use touchscreen menu.



2. Identify apps quickly with a grid list view, abbreviated app names, and categorized menu options.



3. A notification center keeps important information visible to the operator, and displays messages without shrinking the camera view.



4. Color coded notifications set critical messages apart from the rest.



5. Use the in-monitor QR code to learn about machine and technology features through a full suite of “how-to” videos.

Not all features are available in all regions. Please check with your local Cat dealer for specific offering availability in your area. Build Number: 07G

PERFORMANCE WITH LESS FUEL


• The excavator uses up to 20% less fuel than the 320D2 GC in similar applications.



• Match the excavator to the job using power modes; let Smart mode automatically match engine and hydraulic power to your digging conditions.



• The advanced hydraulic system provides the optimum balance of power and efficiency while giving you the control you need for precise digging requirements.



• Valve priority puts hydraulic pressure and flow where you command it to go for fast light- to medium-load cycle times.



• Meets Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3 and EU Stage IIIA.



• Add auxiliary hydraulics to do more work with a range of Cat attachments.



• VisionLink® provides actionable data insights for all assets - regardless of fleet size or equipment manufacturer. Review equipment data from your desktop or mobile device to maximize uptime and optimize assets.



• Don't let the temperature stop you from working. The excavator has a standard high ambient temperature capability of 52º C (125º F) and cold start capability of -32º C (-25º F).

LOWER MAINTENANCE COSTS


• Expect up to 20% less maintenance cost than the 320D2 GC (savings calculated over 12,000 machine hours).



• Do all daily maintenance at ground level.



• Boost productivity with proactive service reminders. The integrated vehicle health management system alerts the operator with step-by-step service guidance along with parts needed so you don't experience any unnecessary downtime.



• Check engine oil level quickly and safely with the latest ground-level engine oil dipstick; fill and check engine oil on top of the machine with a conveniently located second dipstick.



• Track your excavator’s filter life and maintenance intervals via the in-cab monitor.



• No required maintenance on the Cat Clean Emissions Module.



• Using Cat genuine oil and filters and doing your typical S∙O∙S monitoring will double the current service interval to 1,000 hours, giving you greater uptime to do more work.



• The latest hydraulic oil filter provides improved filtration performance,anti-drain valves to keep oil clean when the filter is replaced, and longer life with a 3,000 hour replacement interval – 50% longer than previous filter designs.



• The latest high-efficiency electric cooling fans only run when needed and reverse to keep cores free from debris.



• S·O·S ports simplify maintenance and allow for quick, easy extraction of samples for fluid analysis.

RELIABILITY YOU CAN COUNT ON


• Work up to 3000 m (9,840 ft) above sea level without de-rating.



• Standard high-ambient temperature capability is 52º C (125º F) with cold start capability at –32º C (–25º F).



• Auto warm up speeds up hydraulic oil warming in cold temperatures and helps prolong the life of components.



• Three levels of fuel filtration protect the engine from dirty diesel fuel.



• Grease sealed between track pins and bushings reduces travel noise and prevents debris from entering to increase undercarriage life.



• The center track guiding guard helps keep the excavator track aligned when traveling and working on slopes.



• The sloped track frame prevents mud and debris accumulation, helping reduce risk of track damage.

SAFELY HOME EVERY DAY


• Access 100% of daily maintenance points from ground level – no need for you to climb on top of the excavator.



• Keep your excavator secure with Operator ID. Use your PIN code on the monitor to enable the push button starting feature.



• The standard ROPS cab meets ISO 12117-2:2008 requirements.



• Enjoy great visibility into the trench, in each swing direction, and behind you with the help of smaller cab posts and larger windows.



• A rear view camera is standard, and a right-side-view camera is optional.



• The latest right-hand service platform design provides easy, safe, and quick access to upper service platform; the service platform steps use anti-skid punch plate to prevent slipping.



• The handrails comply with ISO 2867:2011 requirements.



• The lower frame meets ISO 15818:2017 lifting and tie-down requirements.



• Enhance jobsite safety. Add a swing alarm to alert people when you're rotating from trench to stockpile and back again.



• Make service work easier and safer with optional inspection lighting. With the flip of a switch, lights will illuminate the engine, pump, battery, and radiator compartments to enhance visibility.

SIMPLE TO OPERATE


• Start the engine with a push button; use a Bluetooth® key fob, or the unique Operator ID function.



• Program each joystick button, including response and pattern, using Operator ID; it will also remember climate control fan and radio settings.



• Navigate quickly on the standard high-resolution 203 mm (8 in) touchscreen monitor or with the aid of the jog dial control.



• Use the in-monitor QR code to learn about machine and technology features through a full suite of “how-to” videos.



• Protect your hammer tool from overheating and rapid wear. Auto hammer stop warns you after 15 seconds of continuous firing and then automatically shuts it off after 30 seconds - all to extend the tool’s service life.



• The Cat PL161 Attachment Locator is a Bluetooth device that makes finding your attachments and other gear quick and easy.

WORK IN COMFORT


• The Comfort cab has a wide seat that adjusts for operators of all sizes.



• Control the excavator comfortably with easy-to-reach controls all located in front of you.



• Standard automatic climate control keeps you at the right temperature all shift long.



• Advanced viscous mounts reduce cab vibration by up to 50% over previous excavator models.



• Stow your gear with plenty of in-cab storage beneath and behind the seat, overhead, and in the consoles. A cup holder, document holder, bottle holder, and coat hook are also provided.



• Use the standard radio’s USB ports and Bluetooth® technology to connect to personal devices.

TAKE THE GUESSWORK OUT OF MANAGING YOUR EQUIPMENT


• VisionLink® provides actionable data insights for all assets - regardless of fleet size or equipment manufacturer.* Review equipment data from your desktop or mobile device to maximize uptime and optimize assets. Dashboards provide information such as hours, miles, location, idle time, and fuel utilization. Make informed decisions that lower costs, simplify maintenance, and improve safety and security on your jobsite.



• VisionLink Productivity gathers and summarizes machine telematics and jobsite data from all your equipment – regardless of the manufacture.* View actionable information such as idle time, fuel burn, location, payload, load counts, total cycles, and more to improve machine efficiency, productivity, and utilization. Access data anywhere via a mobile, tablet, or desktop device - on or off the jobsite.



• Remote Flash is a mobile application that allows you to update onboard software without a technician being present, allowing you to initiate software updates when convenient, increasing your overall operating efficiency.

* Data field availability can vary by equipment manufacturer.
